Fully Automatic Double Sides Self Adhesive Sticker Labeling Machine

Introduction

This self adhesive labeling machine achieve fast and accurate labeling, stick adhesive paper label or adhesive film label on both sides of the products. Suitable for label whole curved surfaces or half curved surfaces . with advanced touch screen interface which easy to operate. Automatic photoelectric detect functions, such as cancel labels without bottles passing, no need stop running machine or alarm to avoid omitting or waste labels.

Technical parameter

item	Description
1	Labeling capacity	0-50 bottle/min
2	Bottle diameter	10-150mm
3	Inner diameter of label	76mm
4	Max outer diameter of label:	360mm
5	Label width	10-200mm
6	Label length	10-400mm
7	Label precision	±1mm
8	Net weight	500kg
9	Contour Sizes	2800*1500*1700mm

Technical Features and application :

1. This self adhesive labeling machine adopt PLC control, it is made up of photo electricity equipment of Japan OMRON. Synchronization electrical，timing electrical, conveyer belt. Import strap etc correlative part.

2. The design of mainframe part absorbed label transmit of import machine and solved the unsteady ingredient of homemade common label.

3. The machine is suitable for various specifications of bottles. Its operation is easy and it can be finished in a short time.

4. The quick printer adopts the motor drive, gas drive. The words in the ribbon are clear and clean.

5. The whole machine is designed to meet GMP standard.

6. This machine is suitable for processing the big round label of medicine, chemical, food, commodity etc.

7. Label applicable: adhesive paper label or transparent label, bar code or code label etc

8. Product Applicable: round/flat/square/abnormal bottle/drum, box or small carton etc.

Advantages

1. Heavy-duty construction utilizes over-sized drive components combined with an aluminum and staineless steel base frame for years of dependable service.

2. Various product infeed systems are available that provide precise product spacing and orientation. It can be used stand alone or integrated in-line and matching filling equipment speeds.

3. Advanced high torque micro-stepping driven applicators include ratio-offset and speed-following accurate and reliable application of a wide variety of label materials.

4. Designed for the application of front and/or back panel labels with the capability to label containers that are round,square,oval or rectangular.

Features:

1. Advanced easy to operate, simple and intuitive man-machine interface system,the funcation is all ready.

2. Adopt Japan Panasonic control system, make the machine run more stable and longer life.

3. Dividing device, the applicability of any type of the diameter of the bottle without replacement parts, quick adjustment.
